LKMFLQ 4/PCB M8 Flange Panel Mount ConnectorFlange4PinM8Male Flange(PCBBoard Mount)
Product Model：
LKMFLQ 4/PCB
Order No.：
767130
Gender：
M8Male Flange(PCBBoard Mount)
Number of Pins：
4Pin
Coding Position:
A-
PDF:
Electrical and Mechanical Properties
Standard：
IEC 61076-2-104
Connector Type：
Panel Mount Flange Type
Housing Material：
Metal Housing
Insulator Material：
NYLON66 + GF
Contact Material：
Gold Plated Copper
Sealing Method：
Epoxy Resin
Coupling Nut：
Nickel Plated Copper
Insulation Resistance：
≥100 MΩ
Contact Resistance：
≤5mΩ
Protection Rating：
IP67
：
60V AC/DC
：
4A
：
-25°C~+85°C
：
0.14~0.5mm
：
φ8+0.2
M8 Overmoldedwith CableConnector (Plug)Product, mainly used in sensors, machine vision, industrial Ethernet, LED lighting, and related applications. Westlian M8Connectorthe cable is overmolded together before leaving the factory, common jacket material options include PUR and PVC, ProductCore CableStandardPVC, SR-PVC, PP, HDPEMaterial Type, M8Connector (Receptacle) CableSolderPCBMale, M8SolderSolder Cableresin potting encapsulation.
● PURPVCShieldedcable, Custom Cable
● High-quality gold-plated phosphor bronze contacts ensure longer connector mating life
● Excellent wire cutting, stripping, and soldering workmanship
● IP 67, IP68 Protection Rating, suitable for humid, underwater, and outdoor environments
● 3-core, 4-core, and 8-core versions available
● Rated Voltage60V/30V, Rated Current3A/1A
● solid nickel-plated brass screws with an anti-vibration locking design
● Sensors and actuators
● Industrial cameras
● Industrial I/O ports
● Robotics
● Medical equipment
● Industrial batteries and semiconductors
● Industrial packaging and label printing equipment
